- PCB Assembly Service
- 【Brief】：
*LDES Manufacturing Capability:
Types of Assembly: THD (Thru-Hole Device) ; SMT (Surface-Mount Technology) ; SMT & THD mixed ; 2 sided SMT and THD assembly
SMT Line Quantity: 30
SMT Line Quantity: 01005
SMT Min Pitch-QFP: 0.3mm
BGA-Min Pitch: 0.25mm
Component Package: Reels ; Cut tape ;Tube and tray ;Loose parts and bulk
Board dimensions: Smallest size: 50*50mm ; Largest size: 520*420mm
Board shape: Rectangular ; Round ;Slots and Cut outs ;Complex and Irregular
Board type: Rigid FR-4 ; Rigid-Flex boards ; Aluminum PCB
Assembly process: Lead-Free (RoHS)
Design file format: Gerber RS-274X ; BOM (Bill of Materials) (.xls, .csv, . xlsx)
Testing Procedures : Visual inspection ; X-ray Inspection ;AOI (Automated Optical Inspection) ; ICT (In-Circuit Test) ; Functional testing
Turnaround time: 1-5 days for only PCB assembly ; 10-16 days for full turn-key PCB assembly
Technical Requirement Professional Surface-mounting and Through-hole soldering Technology Various sizes like 1206,0805,0603 components SMT technology ICT(In Circuit Test),FCT(Functional Circuit Test) technology PCB Assembly With CE,FCC,Rohs Approval Nitrogen gas reflow soldering technology for SMT High Standard SMT&Solder Assembly Line High density interconnected board placement technology capacity Quote&Production Requirement Gerber File or PCB File for Bare PCB Board Fabrication Bom(Bill of Material) for Assembly,PNP(Pick and Place file) and Components Position also needed in assembly To reduce the quote time, please provide us the full part number for each components,Quantity per board also the quantity for orders. Testing Guide&Function Testing method to ensure the quality to reach nearly 0% scrap rate OEM/ODM/EMS Services PCBA, PCB assembly: SMT & PTH & BGA PCBA and enclosure design Components sourcing and purchasing Quick prototyping Plastic injection molding Metal sheet stamping Final assembly Test: AOI, In-Circuit Test (ICT), Functional Test (FCT) Custom clearance for material importing and product exporting Other PCB Assembly Equipments SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4 Reflow Oven: FolunGwin FL-RX860 Wave Soldering Machine: FolunGwin ADS300 Automated Optical Inspection (AOI): Aleader ALD-H-350B,X-RAY Testing Service Fully Automatic SMT Stencil Printer: FolunGwin Win-5
- 【Series】：PCB Assembly
1. Company profiles:
LDES has the most diversified printed circuit board technologies available, including Single-sided PCB, Multilayer PCB, Aluminum based PCB, HDI PCB, Rigid-flex PCB, Flexible PCB, Heavy Copper PCB, Ceramic PCB, and PCB assembly and other special PCB boards.
We believe that the quality is the soul of an enterprise and provides time-critical, technologically advanced engineering and manufacturing services for the electronic industry.
Sound quality gains a good reputation for Fastline. Loyal customers has cooperated with us again and again and new customers come to Fastline to establish cooperation relationship when they hear of the great reputation. We look forward to offering high-quality service to you!
2.Related products:
4. Qualification of High Density Online Rogers Pcb Circuits Board
We have got ROSH. ISO9001,ISO14001,ISO13485,UL,CE.
5.Application:
